SPARECRUX is NOT an authorized distributor for FESTO

156551 | FESTO | Compact Cylinder ADVU-50-15-P-A

₹ 7,471.33

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

156551

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Stroke 15 mm
Piston diameter 50 mm
Piston rod thread M8
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Female thread
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.08 MPa ... 1 MPa / 0.8 bar ... 10 bar / 11.6 psi ... 145 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.64 J
Theoretical force at 0.6 MPa (return stroke) 1057 N
Theoretical force at 0.6 MPa (advance stroke) 1178 N
Moving mass for 0 mm stroke 112 g
Additional moving mass per 10 mm stroke 16 g
Basic weight for 0 mm stroke 560 g
Additional weight per 10 mm stroke 72 g
Type of mounting With through-hole or with accessories
Pneumatic connection G1/8
Material collar screws Galvanised steel
