SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

16256 | SCHNEIDER ELECTRIC | 40A 4P ELCB 300mA 415V

₹ 3,180.60

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

16256

الشركة المصنعة للمعدات الأصلية

SCHNEIDER ELECTRIC

وصف

Product range Acti9 xID (RCCB)
Device short name A9N16256
Number of poles 4‑Pole
Rated current (In) 40 A
Residual current sensitivity 300 mA (AC type)
Breaking capacity 10 kA
Test button Yes
Standards IEC/EN 61008‑1, EN 61008‑2‑1
Operational voltage (Ue) 400–415 V AC
Insulation voltage (Ui) 500 V AC
Impulse voltage (Uimp) 6 kV
Mounting DIN‑rail, 8 × 9 mm pitch
Dimensions (WxHxD) 72 × 81 × 75 mm
Weight ≈ 370 g
Protection degree IP20 (IP40 in enclosure)
Operating temperature −5…+40 °C
Storage temperature −40…+85 °C
Environment class Pollution degree 2, IEC 60068‑1 compliant
