SPARECRUX is NOT an authorized distributor for FESTO

164274 | FESTO | Angled Plug Socket PEV-1/4-WD-LED-24

₹ 1,183.39

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

164274

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Based on standard EN 175301-803
Switching status indication Yellow LED, Green LED
Type of mounting Screw-clamped
Cable outlet Angled
Electrical connection 1, function Field device side
Electrical connection 1, design Angular
Electrical connection 1, connection type Socket
Electrical connection 1, connector system Plug pattern type A to EN 175301-803
Electrical connection 1, number of connections/cores 4
Electrical connection 1, used connections/cores 4
Electrical connection 1, type of mounting Central screw M3
Electrical connection 2, function Controller side
Electrical connection 2, connector system Screw terminal
Electrical connection 2, number of connections/cores 5
Electrical connection 2, used connections/cores 5
Operational voltage range DC 15 V ... 30 V
Current rating at 40° C 8 A
Cable fitting Pg11
Permissible cable diameter 4.5 mm ... 11 mm
Connection cross section 0.25 mm² ... 1.5 mm²
Degree of protection IP65 (in assembled state)
Ambient temperature -40 °C ... 80 °C
Note on ambient temperature Note derating
CE mark See declaration of conformity
Compliance EU RoHS Directive, UK RoHS instructions
LABS (PWIS) conformity VDMA24364-B2-L
Note on materials RoHS-compliant
Material housing PA6 reinforced
Housing colour Transparent
Material electrical contact Brass, Nickel-plated, Tin-plated
