SPARECRUX is NOT an authorized distributor for FESTO

196025 | FESTO | Round Cylinder DSNU-32-125-PPV-A

₹ 3,822.33

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

196025

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Value
Stroke 125 mm
Piston diameter 32 mm
Piston rod thread M10x1.25
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position Optional
Design Piston, Piston rod, Cylinder barrel
Position detection Via proximity switch
Symbol 00991235
Operating pressure 0.1 MPa ... 1 MPa (1 bar ... 10 bar)
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 6 according to ISO 14644-1
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.4 J
Cushioning length 14 mm
Theoretical force at 0.6 MPa (6 bar), return stroke 415 N
Theoretical force at 0.6 MPa (6 bar), advance stroke 482.5 N
Moving mass 234 g
Product weight 565 g
Type of mounting With accessories
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals NBR, TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel High-alloy stainless steel
FESTO
