SPARECRUX is NOT an authorized distributor for FESTO

197580 | FESTO | One-way Flow Control Valve GRLA-1/8-QS-4-RS-D

₹ 483.34

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

197580

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Valve function Exhaust air one-way flow control function
Pneumatic connection, port 1 QS-4
Pneumatic connection, port 2 G1/8
Adjustment component Knurled screw
Type of mounting Screw-in
Standard nominal flow rate in flow control direction 160 l/min
Standard nominal flow rate in blocked direction 120 l/min ... 190 l/min
Operating pressure 0.2 bar ... 10 bar
Ambient temperature -10 °C ... 60 °C
Maritime classification See certificate
Mounting position Optional
Symbol 00991452
Operating pressure (complete temperature range) 0.2 bar ... 10 bar
Standard flow rate (flow control direction, 6 → 0 bar) 250 l/min
Standard flow rate (non-return direction, 6 → 0 bar) 270 l/min ... 300 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubrication then always required)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Media temperature -10 °C ... 60 °C
Nominal torque 3 Nm
Product weight 23 g
Material screwed plug Wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR (Nitrile Butadiene Rubber)
Material release ring POM (Polyoxymethylene)
Material adjusting screw High-alloy stainless steel
Material swivel fitting Die-cast zinc
Surface treatment of swivel fitting Chromated
