SPARECRUX is NOT an authorized distributor for FESTO

25025 | FESTO | Precision Pressure Regulator MS6-LRP

₹ 22,433.68

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

25025

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Category Specification
Size 6
Series MS
Actuator Lock Rotary knob with detentRotary knob with integrated lockCan be closed with accessories
Mounting Position Optional
Design Piloted precision diaphragm control valvePiloted precision pressure regulator
Controller Function Output pressure constantWith secondary venting
Symbol 009919730099530300995326
Pressure Gauge / Display Pressure gauge (ANALOG) or Pressure display (DIGITAL)
Port Configuration Prepared for G1/4Prepared for G1/8
Monitoring Options Via pressure sensorWith pressure gaugeVia operational status indicator
Operating Pressure 0.1 MPa ... 1.4 MPa1 bar ... 14 bar
Pressure Regulation Range 0.05 bar ... 12 bar
Max. Pressure Hysteresis 0.02 bar ... 0.05 bar
Flow Rate of Secondary Exhaust 220 l/min ... 900 l/min
Standard Nominal Flow Rate 800 l/min ... 9000 l/min (standardised to DIN 1343)
Operational Voltage Range (DC) 21.6 V ... 26.4 V
Max. Electrical Power Consumption 4.2 W
Max. Current Consumption 0.16 A
Nominal Operating Voltage (DC) 24 V
Residual Ripple 10 %
Signal Range - Analog Input 0 - 10 V4 - 20 mA
Approval & Certification c UL us - Recognized (OL)CE markUKCA marking
Directives Compliance EU EMC DirectiveEU ATEX DirectiveEU RoHS DirectiveUK EMC/EX/RoHS Instructions
Explosion Protection Certification (Non-EU) EPL Db (GB)EPL Gb (GB)
Explosion Protection Zones Zone 1 (ATEX/UKEX)Zone 2 (ATEX)Zone 21 (ATEX/UKEX)Zone 22 (ATEX)
ATEX Category - Gas II 2G
ATEX Category - Dust II 2D
Explosion Protection Type - Gas Ex h IIC T6 Gb X
Explosion Protection Type - Dust Ex h IIIC T60°C Db X
Explosion Ambient Temperature -10 °C ≤ Ta ≤ +60 °C
FESTO

25025 | FESTO | Precision Pressure Regulator MS6-LRP

₹ 22,433.68
Category Specification
Size 6
Series MS
Actuator Lock Rotary knob with detentRotary knob with integrated lockCan be closed with accessories
Mounting Position Optional
Design Piloted precision diaphragm control valvePiloted precision pressure regulator
Controller Function Output pressure constantWith secondary venting
Symbol 009919730099530300995326
Pressure Gauge / Display Pressure gauge (ANALOG) or Pressure display (DIGITAL)
Port Configuration Prepared for G1/4Prepared for G1/8
Monitoring Options Via pressure sensorWith pressure gaugeVia operational status indicator
Operating Pressure 0.1 MPa ... 1.4 MPa1 bar ... 14 bar
Pressure Regulation Range 0.05 bar ... 12 bar
Max. Pressure Hysteresis 0.02 bar ... 0.05 bar
Flow Rate of Secondary Exhaust 220 l/min ... 900 l/min
Standard Nominal Flow Rate 800 l/min ... 9000 l/min (standardised to DIN 1343)
Operational Voltage Range (DC) 21.6 V ... 26.4 V
Max. Electrical Power Consumption 4.2 W
Max. Current Consumption 0.16 A
Nominal Operating Voltage (DC) 24 V
Residual Ripple 10 %
Signal Range - Analog Input 0 - 10 V4 - 20 mA
Approval & Certification c UL us - Recognized (OL)CE markUKCA marking
Directives Compliance EU EMC DirectiveEU ATEX DirectiveEU RoHS DirectiveUK EMC/EX/RoHS Instructions
Explosion Protection Certification (Non-EU) EPL Db (GB)EPL Gb (GB)
Explosion Protection Zones Zone 1 (ATEX/UKEX)Zone 2 (ATEX)Zone 21 (ATEX/UKEX)Zone 22 (ATEX)
ATEX Category - Gas II 2G
ATEX Category - Dust II 2D
Explosion Protection Type - Gas Ex h IIC T6 Gb X
Explosion Protection Type - Dust Ex h IIIC T60°C Db X
Explosion Ambient Temperature -10 °C ≤ Ta ≤ +60 °C
