SPARECRUX is NOT an authorized distributor for WAGO

283-101 | WAGO | 2-Conductor Through Terminal Block, 16 mm², CAGE CLAMP®, Gray, DIN-Rail

₹ 1,010.82

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

283-101

الشركة المصنعة للمعدات الأصلية

WAGO

وصف

Property Details
Connection technology CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Solid conductor 0.2 … 16 mm² / 24 … 6 AWG
Fine-stranded conductor 0.2 … 16 mm² / 24 … 6 AWG
Strip length 16 … 17 mm / 0.63 … 0.67 inches
Wiring direction Side-entry wiring
Design Horizontal type
Mounting type DIN-35 rail
Marking level Side marking
Width 12 mm / 0.472 inches
Height 58 mm / 2.283 inches
Depth from upper-edge of DIN-rail 45.5 mm / 1.791 inches
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.374 MJ
Weight 27.2 g
WAGO

283-101 | WAGO | 2-Conductor Through Terminal Block, 16 mm², CAGE CLAMP®, Gray, DIN-Rail

₹ 1,010.82
Property Details
Connection technology CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Solid conductor 0.2 … 16 mm² / 24 … 6 AWG
Fine-stranded conductor 0.2 … 16 mm² / 24 … 6 AWG
Strip length 16 … 17 mm / 0.63 … 0.67 inches
Wiring direction Side-entry wiring
Design Horizontal type
Mounting type DIN-35 rail
Marking level Side marking
Width 12 mm / 0.472 inches
Height 58 mm / 2.283 inches
Depth from upper-edge of DIN-rail 45.5 mm / 1.791 inches
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.374 MJ
Weight 27.2 g
