SPARECRUX is NOT an authorized distributor for FESTO

30943 | FESTO | Plug Socket With Cable KME-1-24-2.5-LED

₹ 1,222.84

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

30943

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Feature Specification
Signal status display Yellow LED
Type of mounting On solenoid valve via M3 central screw
Mounting position Optional
Product weight 135 g
Electrical connection 1 Angled socket, square design, 3-pin, type C
Electrical connection 2 Open end, 2-wire
Nominal operating voltage DC 24 V
Current rating at 40° C 4 A
Protective conductor connection Not available
Cable length 2.5 m
Cable characteristic For static applications
Min. cable bending radius 52 mm
Cable diameter 5.2 mm
Cable diameter tolerance ± 0.1 mm
Cable structure 2 x 0.75 mm²
Degree of protection IP67
Standard To IEC 60529
Ambient temperature -20 °C ... 80 °C
CE mark In accordance with EU RoHS Directive
UKCA marking To UK RoHS instructions
LABS (PWIS) conformity VDMA24364-B2-L
Corrosion resistance class CRC 1 - Low corrosion stress
Material cable sheath PVC
Material housing TPE-U(PU)
Material seals NBR
Material electrical contact Silver-plated copper alloy
FESTO

30943 | FESTO | Plug Socket With Cable KME-1-24-2.5-LED

₹ 1,222.84
Feature Specification
Signal status display Yellow LED
Type of mounting On solenoid valve via M3 central screw
Mounting position Optional
Product weight 135 g
Electrical connection 1 Angled socket, square design, 3-pin, type C
Electrical connection 2 Open end, 2-wire
Nominal operating voltage DC 24 V
Current rating at 40° C 4 A
Protective conductor connection Not available
Cable length 2.5 m
Cable characteristic For static applications
Min. cable bending radius 52 mm
Cable diameter 5.2 mm
Cable diameter tolerance ± 0.1 mm
Cable structure 2 x 0.75 mm²
Degree of protection IP67
Standard To IEC 60529
Ambient temperature -20 °C ... 80 °C
CE mark In accordance with EU RoHS Directive
UKCA marking To UK RoHS instructions
LABS (PWIS) conformity VDMA24364-B2-L
Corrosion resistance class CRC 1 - Low corrosion stress
Material cable sheath PVC
Material housing TPE-U(PU)
Material seals NBR
Material electrical contact Silver-plated copper alloy
