SPARECRUX is NOT an authorized distributor for FESTO

34574 | FESTO | Shock Absorber YSR-20-25-C

₹ 7,996.58

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

34574

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Size 20
Stroke 25 mm
Cushioning Self-adjusting
Mounting position Optional
Position detection Without
Symbol 00991497
Max. impact speed 3 m/s
Reset time at room temperature 0.3 s
Reset time at min. ambient temperature 1 s
Mode of operation Pushing, Single-acting
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -10 °C ... 80 °C
Cushioning length 25 mm
Max. stop force 3000 N
Max. energy consumption per stroke 60 J
Max. energy consumption per hour 92000 J
Max. residual energy 0.32 J
Reset force 10 N
Min. insertion force 100 N
Product weight 318 g
Load range 120 kg
Type of mounting Via lock nut
Note on materials RoHS-compliant
Material seals NBR
Material housing Galvanised steel
Material piston rod High-alloy steel
FESTO

34574 | FESTO | Shock Absorber YSR-20-25-C

₹ 7,996.58
Parameter Specification
Size 20
Stroke 25 mm
Cushioning Self-adjusting
Mounting position Optional
Position detection Without
Symbol 00991497
Max. impact speed 3 m/s
Reset time at room temperature 0.3 s
Reset time at min. ambient temperature 1 s
Mode of operation Pushing, Single-acting
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -10 °C ... 80 °C
Cushioning length 25 mm
Max. stop force 3000 N
Max. energy consumption per stroke 60 J
Max. energy consumption per hour 92000 J
Max. residual energy 0.32 J
Reset force 10 N
Min. insertion force 100 N
Product weight 318 g
Load range 120 kg
Type of mounting Via lock nut
Note on materials RoHS-compliant
Material seals NBR
Material housing Galvanised steel
Material piston rod High-alloy steel
