SPARECRUX is NOT an authorized distributor for FESTO

34583 | FESTO | Plug Socket MSSD-C

₹ 149.74

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

34583

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Maritime classification See certificate
Mounting type On solenoid valve via M3 central screw
Cable outlet Angled, 90° rotatable
Mounting position Optional
Product weight 22 g
Electrical connection type 3-pin angled socket, Type A
Connection standard DIN EN 175301-803
Connector design Square (MSC / MSN1)
Electrical connection 1: design Angular
Electrical connection 1: type Socket
Electrical connection 1: cable outlet Angled
Electrical connection 1: number of cores 3
Electrical connection 1: pattern 00995648
Electrical connection 2 Screw terminal
Operational voltage (DC) 0 V ... 300 V
Operational voltage (AC) 0 V ... 250 V
Current rating at 40°C 16 A
Protective conductor connection Available
Cable fitting Pg 9
Cable diameter 6 mm ... 8 mm
Nominal conductor cross section ≤ 1.5 mm²
Degree of protection IP65 (in assembled state)
Ambient temperature -25 °C ... 90 °C
Storage temperature -40 °C ... 90 °C
CE marking According to EU Low Voltage Directive and EU RoHS Directive
UKCA marking According to UK RoHS and UK electrical equipment regulations
LABS (PWIS) conformity VDMA24364-B2-L
Material housing Polymer
Housing colour Black
Material seals NBR
