50044 | MURRELEKTRONIK | Opto-coupler Module N, 53 Vdc - Out, 53 Vdc / 4 A

₹ 6,600.00

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

50044

الشركة المصنعة للمعدات الأصلية

SpareCrux

وصف

Parameter Details
Manufacturer Murrelektronik
Part Number 50044
Product Type Optocoupler Relay / Opto-Coupler Module
Model AMS 10-43/5
Input Voltage (Control) 10–53 V DC
Output Switching Voltage 4.5–53 V DC
Output Current Max. 4 A
Output Type Transistor
Switching Frequency Max. 2000 Hz (resistive load)
Switching Time ON/OFF 4 µs / 7 µs
Isolation Voltage 3.75 kV
LED Indicator Red LED status indication
Mounting Type DIN Rail mounting (TH35 / G32)
Connection Type Screw terminal
Housing Material Flame-retardant plastic
Dimensions (W × H × D) 22.5 × 75 × 85 mm
Operating Temperature -20°C to +60°C
Weight Approx. 100–190 g
Protection / Compliance RoHS compliant
Country of Origin Czech Republic (CZ)
Application PLC interface, industrial automation, signal isolation, DC load switching
