SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

5058 | FESTO | ISO Cylinder DSN-16-40-P

₹ 7,060.40

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

5058

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Feature Specification
Model DSN-16-40-P (5058)
Cylinder Type ISO Cylinder (DSN series)
Nominal Bore Size 16 mm
Stroke Length 40 mm
Mounting Type Pneumatic connection with male thread (M5)
Cushioning Pneumatic cushioning at both ends
Operating Pressure 1 to 10 bar
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient Temperature Range -20 °C to 80 °C
Corrosion Resistance Class CRC 1 – Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Position Detection Not available
Piston Rod Thread M6
Cylinder Design Piston rod with profile barrel
Materials Housing: High-alloy steel barrel and piston rod
Seals: NBR
Weight Not specified
Additional Features Flexible polymer end position cushioning
FESTO

5058 | FESTO | ISO Cylinder DSN-16-40-P

₹ 7,060.40
Feature Specification
Model DSN-16-40-P (5058)
Cylinder Type ISO Cylinder (DSN series)
Nominal Bore Size 16 mm
Stroke Length 40 mm
Mounting Type Pneumatic connection with male thread (M5)
Cushioning Pneumatic cushioning at both ends
Operating Pressure 1 to 10 bar
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient Temperature Range -20 °C to 80 °C
Corrosion Resistance Class CRC 1 – Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Position Detection Not available
Piston Rod Thread M6
Cylinder Design Piston rod with profile barrel
Materials Housing: High-alloy steel barrel and piston rod
Seals: NBR
Weight Not specified
Additional Features Flexible polymer end position cushioning
