SPARECRUX is NOT an authorized distributor for FESTO

527663 | FESTO | Pressure Regulator MS6-LR

₹ 3,187.25

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

527663

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Property Value
Size 6
Series MS
Actuator lock Rotary knob with detent, integrated lock, closable with accessories
Mounting position Optional
Design Pressure regulator (with or without pressure gauge)
Controller function Output pressure constant via primary pressure compensation with secondary venting
Pressure display Analog pressure gauge or digital display
Prepared for G1/4, G1/8
Operating pressure 0.8 bar – 20 bar
Pressure regulation range 0.3 bar – 16 bar
Max. pressure hysteresis 0.25 bar
Nominal flow rate 2200 l/min – 7500 l/min (DIN 1343)
Approvals c UL us, CE, UKCA, ATEX, UKEX
Explosion protection zones Zone 1, Zone 2, Zone 21, Zone 22
ATEX Categories II 2G (gas), II 2D (dust)
Explosion protection type Ex h IIC T6 Gb X (gas), Ex h IIIC T60°C Db X (dust)
Explosion ambient temp -10 °C to +60 °C
Operating medium Compressed air (ISO 8573-1:2010 [7:4:4]), inert gases
Lubricated operation Possible (must be continued if started)
Corrosion resistance class CRC 2 (Moderate)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10 °C to 60 °C
Suitable for food use See supplementary info
Media temperature -10 °C to 60 °C
Ambient temperature -10 °C to 60 °C
Mounting options Front panel, in-line, with accessories
Material (seals) NBR
Material (housing) Die-cast aluminium
RoHS-compliant Yes
FESTO

527663 | FESTO | Pressure Regulator MS6-LR

₹ 3,187.25
Property Value
Size 6
Series MS
Actuator lock Rotary knob with detent, integrated lock, closable with accessories
Mounting position Optional
Design Pressure regulator (with or without pressure gauge)
Controller function Output pressure constant via primary pressure compensation with secondary venting
Pressure display Analog pressure gauge or digital display
Prepared for G1/4, G1/8
Operating pressure 0.8 bar – 20 bar
Pressure regulation range 0.3 bar – 16 bar
Max. pressure hysteresis 0.25 bar
Nominal flow rate 2200 l/min – 7500 l/min (DIN 1343)
Approvals c UL us, CE, UKCA, ATEX, UKEX
Explosion protection zones Zone 1, Zone 2, Zone 21, Zone 22
ATEX Categories II 2G (gas), II 2D (dust)
Explosion protection type Ex h IIC T6 Gb X (gas), Ex h IIIC T60°C Db X (dust)
Explosion ambient temp -10 °C to +60 °C
Operating medium Compressed air (ISO 8573-1:2010 [7:4:4]), inert gases
Lubricated operation Possible (must be continued if started)
Corrosion resistance class CRC 2 (Moderate)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10 °C to 60 °C
Suitable for food use See supplementary info
Media temperature -10 °C to 60 °C
Ambient temperature -10 °C to 60 °C
Mounting options Front panel, in-line, with accessories
Material (seals) NBR
Material (housing) Die-cast aluminium
RoHS-compliant Yes
