SPARECRUX is NOT an authorized distributor for FESTO

529156 | FESTO | Filter Regulator MS4-LFR-1/4-D7-ERM-AS

₹ 2,529.90

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

529156

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Specification Details
Size 4
Series MS
Actuator lock Rotary knob with detent (closable with accessory)
Mounting position Vertical ±5°
Grade of filtration 40 µm
Pore size < 40 µm
Condensate drain Manually rotating
Design Filter regulator with pressure gauge
Max. condensate volume 19 ml
Controller function Output pressure constant, with secondary venting and return flow function
Bowl guard Plastic
Degree of condensate separation >75%
Symbol 00991589
Pressure display With analog pressure gauge
Operating pressure 0.08 MPa – 1.4 MPa (0.8 bar – 14 bar)
Pressure regulation range 0.5 bar – 12 bar
Max. pressure hysteresis 0.25 bar
Standard nominal flow rate 1500 l/min (DIN 1343)
Operating medium Inert gases
Air purity class (output) ISO 8573-1:2010 [7:4:4]
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Suitable for use with food See supplementary material info
Storage temperature -10 °C to 60 °C
Media temperature -10 °C to 60 °C
Ambient temperature -10 °C to 60 °C
Product weight 275 g
Mounting type With accessories
Pneumatic connection, ports 1 & 2 G1/4
Note on materials RoHS-compliant
