SPARECRUX is NOT an authorized distributor for FESTO

529785 | FESTO | Lubricator MS6-LOE-3/8-U

₹ 3,605.20

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

529785

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Size 6
Series MS
Mounting position Vertical ±5°
Design Proportional standard mist lubricator
Max. oil capacity 80 cm³
Bowl guard Integrated as metal bowl
Symbol 00991532
Operating pressure 1 bar ... 16 bar
Min. flow rate for lubricator function 50 l/min
Standard nominal flow rate (standardised to DIN 1343) 5300 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Inert gases
Note on operating and pilot medium Lubricated operation possible
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10 °C ... 60 °C
Suitable for use with food See supplementary material information
Media temperature -10 °C ... 60 °C
Oil viscosity ISO VG 32
Ambient temperature -10 °C ... 60 °C
Product weight 810 g
Type of mounting With accessories
Pneumatic connection, port 1 G3/8
Pneumatic connection, port 2 G3/8
Note on materials RoHS-compliant
Material housing Die-cast aluminium
Material bowl Wrought aluminium alloy
