SPARECRUX is NOT an authorized distributor for FESTO

531694 | FESTO | Quick Coupling Socket KD4-1/4-A-R

₹ 883.40

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

531694

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Feature Specification
Nominal size 8 mm
Operating pressure (complete range) -0.095 MPa ... 1.2 MPa (-0.95 bar ... 12 bar)
Operating pressure (psi) -13.775 psi ... 174 psi
Standard nominal flow rate (DIN 1343) 765 l/min
Nominal flow rate (ISO 8778) 829.3 l/min
Operating medium Compressed air (ISO 8573-1:2010 [7:-:-])
Lubricated operation possible Yes
Corrosion resistance class (CRC) 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10 °C ... 60 °C
Nominal torque 9.5 Nm
Torque tolerance ± 15%
Product weight 58 g
Pneumatic connection, port 1 Male thread G1/4
Material seals NBR
Material spring High-alloy stainless steel
Material housing Brass
Material thread seal PA66-GF30 / TPE-U
Material thread piece Brass
Material of inner raceway Brass
Material snap ring High-alloy stainless steel
Material pins High-alloy stainless steel
Valve body material Brass
Material releasing sleeve PP
Note on materials RoHS-compliant
FESTO
