SPARECRUX is NOT an authorized distributor for FESTO

535987 | FESTO | Solenoid Valve NVF3-MOH-5/2-K-1/4-EX

₹ 6,051.81

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

535987

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Parameter Value
Valve function 5/2- or 3/2-way monostable
Type of actuation Electric
Construction width 53 mm
Standard nominal flow rate (standardised to DIN 1343) 900 l/min
Pneumatic working port Sub-base
Operating voltage Via solenoid coil, must be ordered separately
Operating pressure 0.2 MPa ... 1 MPa
Operating pressure 2 bar ... 10 bar
Design Poppet seat
Type of reset Mechanical spring
CE mark To EU Explosion Protection Directive (ATEX)
Explosion protection certification outside the EU EPL Db (GB), EPL Gb (GB)
UKCA marking To UK EX instructions
ATEX category gas II 2G
ATEX category dust II 2D
Explosion ignition protection type for gas Ex h IIC T6 Gb
Explosion ignition protection type for dust Ex h IIIC T70°C Db
Explosion ambient temperature -5 °C ≤ Ta ≤ +40 °C
Nominal size 7 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
Conforms to standard VDI/VDE 3845 (NAMUR)
Manual override Detenting, Non-detenting
Type of piloting Pilot actuated
Flow direction Non-reversible
Symbol 00991831
Lap Underlap
b value 0.33
C value 4.2 l/sbar
Switching time off 100 ms
Switching time on 50 ms
Explosion protection Zones Zone 1 (ATEX), Zone 1 (UKEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 21 (UKEX), Zone 22 (ATEX)
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -5 °C ... 40 °C
Ambient temperature -5 °C ... 40 °C
Product weight 280 g
