SPARECRUX is NOT an authorized distributor for SICK SENSORS

6077703 | SICK SENSORS | UC12-1223E Ultrasonic Distance Sensor

₹ 24,647.20

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

6077703

الشركة المصنعة للمعدات الأصلية

SICK SENSORS

وصف

Operating range, limiting range 55 mm ... 250 mm, 350 mm
Target Natural objects
Resolution ≥ 0.1 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Temperature compensation
Response time 30 ms
Switching frequency 25 Hz
Output time 8 ms
Ultrasonic frequency (typical) 500 kHz
Dimensions (W x H x D) 15 mm x 48.8 mm x 43.5 mm
Design Rectangular
Sending axis Straight
Housing material Metal (zinc diecast, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 75 g
Connection type Male connector, M12, 4-pin



SICK SENSORS 6077703 UC12-1223E Ultrasonic Distance Sensor
SICK SENSORS

6077703 | SICK SENSORS | UC12-1223E Ultrasonic Distance Sensor

₹ 24,647.20
Operating range, limiting range 55 mm ... 250 mm, 350 mm
Target Natural objects
Resolution ≥ 0.1 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Temperature compensation
Response time 30 ms
Switching frequency 25 Hz
Output time 8 ms
Ultrasonic frequency (typical) 500 kHz
Dimensions (W x H x D) 15 mm x 48.8 mm x 43.5 mm
Design Rectangular
Sending axis Straight
Housing material Metal (zinc diecast, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 75 g
Connection type Male connector, M12, 4-pin
