SPARECRUX is NOT an authorized distributor for FESTO

6145 | FESTO | Rod Clevis SG-M12X1,25

₹ 226.98

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

6145

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Size M12x1.25
Conforms to standard ISO 8140
Threaded connection Female thread M12x1.25
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Suitability for the production of Li-ion batteries Metals with more than 1% by mass of copper are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils
Ambient temperature -40 °C ... 150 °C
Max. load capacity 1.5 kN
Product weight 166 g
Note on materials RoHS-compliant
Material bolt Steel, Galvanised
Material clevis Steel, Galvanised
Material nut Steel, Galvanised
FESTO

6145 | FESTO | Rod Clevis SG-M12X1,25

₹ 226.98
Parameter Specification
Size M12x1.25
Conforms to standard ISO 8140
Threaded connection Female thread M12x1.25
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Suitability for the production of Li-ion batteries Metals with more than 1% by mass of copper are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils
Ambient temperature -40 °C ... 150 °C
Max. load capacity 1.5 kN
Product weight 166 g
Note on materials RoHS-compliant
Material bolt Steel, Galvanised
Material clevis Steel, Galvanised
Material nut Steel, Galvanised
