SPARECRUX is NOT an authorized distributor for WAGO

750-402 | WAGO | 4-Channel Digital Input, 24 VDC, 3 ms

₹ 9,309.05

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

750-402

الشركة المصنعة للمعدات الأصلية

WAGO

وصف

Parameter Value
Connection technology: I/O 8 x CAGE CLAMP® (inputs)
Connectable conductor materials Copper
Connection type Input
Solid conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 inches
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Color light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 1.028 MJ
Weight 45.5 g
Conformity marking CE
WAGO

750-402 | WAGO | 4-Channel Digital Input, 24 VDC, 3 ms

₹ 9,309.05
Parameter Value
Connection technology: I/O 8 x CAGE CLAMP® (inputs)
Connectable conductor materials Copper
Connection type Input
Solid conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 inches
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Color light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 1.028 MJ
Weight 45.5 g
Conformity marking CE
