SPARECRUX is NOT an authorized distributor for WAGO

788-312 | WAGO | Relay Module, Nominal Input Voltage, 24 VDC, 2 Changeover Contacts, Module Width, 15 mm, 2,50 mm², Gray

₹ 1,435.98

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

788-312

الشركة المصنعة للمعدات الأصلية

WAGO

وصف

Nominal Input Voltage (UN) 24 VDC
Input Voltage Range ±10%
Nominal Input Current at UN 19 mA
Number of Changeover/Switchover Contacts 2
Contact Material (Relay) AgNi 90/10
Limiting Continuous Current 8 A
Inrush Current (Resistive), Max. 15 A / 4 s (AC)
Switching Voltage, Max. 250 VAC
Switching Power (Resistive), Max. AC: 2000 VA; DC: Refer to load limit curve
Switching Capacity AC-15: 3 A / 250 VAC; DC-13: 2 A / 24 VDC
Recommended Minimum Load 12 V / 10 mA
Pull-in Time (Typical) 8 ms
Width 15 mm / 0.591 inches
Height 86 mm / 3.386 inches
Depth from Upper-Edge of DIN-Rail 54 mm / 2.126 inches
Color Gray
Fire Load 1.35 MJ
Weight 45.5 g
