SPARECRUX is NOT an authorized distributor for FESTO

9541 | FESTO | Ball Valve QH-1/4

₹ 708.82

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

9541

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Value
Valve function 2/2 bistable
Pneumatic connection, port 1 G1/4
Pneumatic connection, port 2 G1/4
Type of actuation Manual
Type of mounting In-line installation
Standard nominal flow rate 3400 l/min (standardised to DIN 1343)
Nominal size 12 mm
Material housing Brass
Sealing principle Soft
Mounting position Optional
Conforms to standard ISO 228-1
Design Ball valve
Symbol 00991458
Nominal pressure PN 40
Corrosion resistance class (CRC) 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Medium Compressed air (ISO 8573-1:2010 [-:-:-])Inert gasesWater (no water vapour)Neutral fluidsOther media on request
Media temperature -20 °C ... 150 °C
Product weight 180 g
Material seals FPM, PTFE
Material ball Brass, chrome-plated
Material shaft Brass
