SPARECRUX is NOT an authorized distributor for SMC CORPORATION

C96SD40-25 | SMC CORPORATION | Tie-Rod Cylinder

₹ 9,629.56

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

C96SD40-25

الشركة المصنعة للمعدات الأصلية

SMC CORPORATION

وصف

Feature Details
Series CP96
Type Double-acting, single rod
Bore Size 40 mm
Stroke Length 25 mm
Mounting Type Standard (basic), foot, front/rear flange, clevis, trunnion
Operating Pressure 0.05 to 1.0 MPa
Proof Pressure 1.5 MPa
Temperature Range -20°C to +70°C (without auto switch); -10°C to +60°C (with auto switch)
Lubrication Non-lube (factory lubricated)
Cushion Air cushion and bumper cushion
Piston Speed 50 to 1000 mm/s
Auto Switch Mounting Slide-in type (M9, A9, CNOMO grooves on all four sides)
Applications General industrial automation, robotics, material handling
SMC CORPORATION

C96SD40-25 | SMC CORPORATION | Tie-Rod Cylinder

₹ 9,629.56
Feature Details
Series CP96
Type Double-acting, single rod
Bore Size 40 mm
Stroke Length 25 mm
Mounting Type Standard (basic), foot, front/rear flange, clevis, trunnion
Operating Pressure 0.05 to 1.0 MPa
Proof Pressure 1.5 MPa
Temperature Range -20°C to +70°C (without auto switch); -10°C to +60°C (with auto switch)
Lubrication Non-lube (factory lubricated)
Cushion Air cushion and bumper cushion
Piston Speed 50 to 1000 mm/s
Auto Switch Mounting Slide-in type (M9, A9, CNOMO grooves on all four sides)
Applications General industrial automation, robotics, material handling
