SPARECRUX is an authorized distributor for CONNECTWELL

CRS4COY | CONNECTWELL | Modular Industrial Purpose Relay Socket

₹ 156.00

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

CRS4COY

الشركة المصنعة للمعدات الأصلية

CONNECTWELL

وصف

Specification Details
Brand Connectwell
Model / Part Number CRS4COY
Type 4CO (QPDT) Modular Industrial Purpose Relay Socket
Relay Base 4CO Relay Base
Rated Current / Channel 10 A
Rated Voltage 250 V
Bussing Possibility Yes
Ambient Operating Temperature -40 to +55 °C
Mounting Possibility DIN32 / DIN35 / DIN35-15 / Panel
Housing Material PA6,6 V0 Grade
Housing Colour Grey
Connection Type Screw Connection
Min. Wire Size 0.2 mm²
Max. Wire Size 4 mm²
Min. Wire Size (AWG) 24 AWG
Max. Wire Size (AWG) 10 AWG
Features Universal DIN Rail Mountable, DIN Rail & Panel Mountable, Laser Etched Marking, Guided Wire Entry, V0 Flame Retardant, Spring Loaded Snap Lock
Application Industrial relay socket for modular systems
