SPARECRUX is NOT an authorized distributor for FESTO

DSBG-125-325-PPVA-N3 | FESTO | ISO Cylinder

₹ 37,504.48

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

DSBG-125-325-PPVA-N3

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Stroke 1 mm ... 2800 mm
Piston diameter 125 mm
Piston rod thread M27x2
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston
Piston rod Tie rod
Cylinder barrel
Position detection Via proximity switch
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 2.5 J
Cushioning length 45 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 6881 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 7363 N
Moving mass for 0 mm stroke 2245 g
Additional moving mass per 10 mm stroke 63 g
Basic weight for 0 mm stroke 6611 g
