SPARECRUX is NOT an authorized distributor for LAPP GROUP

ÖLFLEX® UNIPLUS 1X16 GNYE | LAPP GROUP | Single core cable; 1X16

₹ 15,868.80

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

ÖLFLEX® UNIPLUS 1X16 GNYE

الشركة المصنعة للمعدات الأصلية

LAPP GROUP

وصف

Specification Details
Product Type Single core cable
Weight 175 kg/km
Copper Index 153.600 kg/km
Single Core Packaging Type Ring
Nominal Voltage 1.1 kV AC rms according to Indian standard
Test Voltage 3 kV
Current Rating According to IS 3961
Cable Dimension 1X16
Conductor Cross-Section 16 mm²
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Number of Cores 1
Nominal Outer Diameter 7.2 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride (PVC)
Application Area Fixed Installation, Flexible
Minimum Bending Radius (Fixed Installation) 6 × outer diameter
Minimum Bending Radius in mm (Stationary) 43.2 mm
Minimum Bending Radius (Occasionally Moved) 8 × outer diameter
Minimum Bending Radius in mm (Occasionally Flexing) 57.6 mm
Temperature (Fixed Installation) -40 °C to +80 °C
Temperature (Occasionally Moved) -15 °C to +70 °C
