QTD20.241 | PULS | Power Supply DC24-28V , 20-17A

₹ 30,400.00

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

QTD20.241

الشركة المصنعة للمعدات الأصلية

PULS

وصف

Parameter Specification
Model QTD20.241
Brand PULS
Product Type DC/DC DIN Rail Converter
Series DIMENSION Q-Series
Input Voltage DC 600V (-20% to +40%)
Output Voltage 24V DC (adjustable 24–28V)
Output Current 20A
Output Power 480W (600W peak for 4 sec)
Efficiency ~95%
Mounting DIN Rail (TS35)
Dimensions 65 × 124 × 127 mm
Weight ~0.89 kg
Operating Temp -25°C to +70°C
Protection Overload, short circuit, reverse polarity, thermal protection
Application Servo drives, automation systems, DC bus power systems
