SPARECRUX is an authorized distributor for KARAM

SA 43 | KARAM | Hexapod

₹ 159,194.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

SA 43

الشركة المصنعة للمعدات الأصلية

KARAM

وصف
Specification Details
Model Number SA43
Alternate Variant SA43(W) (with wheels)
Height 2.15 m
Maximum Span Length 2300 mm
Maximum Load Capacity 500 kg
Weight 51.29 kg (SA43) / 53.28 kg (SA43(W))
Material – Legs and Head Aluminium alloy legs & cast head; high-strength alloy steel rail-support sub-assembly; stainless steel locking pins
Certifications EN 795:2012 Type B, TS 16415:2013 Type B, ATEX 2014/34/EU
Intended Use Entry, rescue and lifting in confined spaces (trenches, large openings, mines, lift shafts) with larger hole size
Features • Mobile roller pulley used as an anchor to provide user mobility over span of 2300 mm.
• Stopper to locate anchorage point above user.
• Two auxiliary eyebolts per tripod leg for attachment.
• Steel support shoes with rubber sole for increased friction and stability.
• Fixture to mount winch and retrieval block (e.g., PN801A, PCGS20R, PCGS30R) when used with mounting bracket PN800(45).
Warranty 1 year from date of invoice against manufacturing defects
KARAM

SA 43 | KARAM | Hexapod

₹ 159,194.00
Specification Details
Model Number SA43
Alternate Variant SA43(W) (with wheels)
Height 2.15 m
Maximum Span Length 2300 mm
Maximum Load Capacity 500 kg
Weight 51.29 kg (SA43) / 53.28 kg (SA43(W))
Material – Legs and Head Aluminium alloy legs & cast head; high-strength alloy steel rail-support sub-assembly; stainless steel locking pins
Certifications EN 795:2012 Type B, TS 16415:2013 Type B, ATEX 2014/34/EU
Intended Use Entry, rescue and lifting in confined spaces (trenches, large openings, mines, lift shafts) with larger hole size
Features • Mobile roller pulley used as an anchor to provide user mobility over span of 2300 mm.
• Stopper to locate anchorage point above user.
• Two auxiliary eyebolts per tripod leg for attachment.
• Steel support shoes with rubber sole for increased friction and stability.
• Fixture to mount winch and retrieval block (e.g., PN801A, PCGS20R, PCGS30R) when used with mounting bracket PN800(45).
Warranty 1 year from date of invoice against manufacturing defects
