SPARECRUX is NOT an authorized distributor for LAPP GROUP

0011167 | LAPP GROUP | Power And Control Cable, 7g4, U0/U: 300/500 V, Pvc

₹ 95.00

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

0011167

Fabricant d'équipement d'origine

LAPP GROUP

Description

Specification Details
Brand ÖLFLEX®
Product Type Power and control cable
Weight 383 kg/km
Copper Index 268.800 kg/km
Copper Index (lb) 592.600 lb/10,000 ft
Nominal Voltage U0/U: 300/500 V AC rms (IEC)
Rated Voltage 600 V AC rms (UL/CSA)
Test Voltage 4 kV
Max. Conductor Resistance (20°C) 4.95 Ω/km
Cable Dimension 7G4
Conductor Cross-Section 4 mm²
Nominal Cross Section (AWG) 12 AWG
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: Fine-wire
Nominal Outer Diameter 13.4 mm
Shape of Cable Round
Core Insulation Material Polyvinylchloride (PVC)
Outer Sheath Material Polyvinylchloride (PVC)
Cable Insulation Colour Grey
Core Identification Numbers
Core Colour Code VDE 0293-1
Wire Per Meter
LAPP GROUP

0011167 | LAPP GROUP | Power And Control Cable, 7g4, U0/U: 300/500 V, Pvc

₹ 95.00
Specification Details
Brand ÖLFLEX®
Product Type Power and control cable
Weight 383 kg/km
Copper Index 268.800 kg/km
Copper Index (lb) 592.600 lb/10,000 ft
Nominal Voltage U0/U: 300/500 V AC rms (IEC)
Rated Voltage 600 V AC rms (UL/CSA)
Test Voltage 4 kV
Max. Conductor Resistance (20°C) 4.95 Ω/km
Cable Dimension 7G4
Conductor Cross-Section 4 mm²
Nominal Cross Section (AWG) 12 AWG
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: Fine-wire
Nominal Outer Diameter 13.4 mm
Shape of Cable Round
Core Insulation Material Polyvinylchloride (PVC)
Outer Sheath Material Polyvinylchloride (PVC)
Cable Insulation Colour Grey
Core Identification Numbers
Core Colour Code VDE 0293-1
Wire Per Meter
