1072697 | SICK SENSORS | IMB08-02BPSVU2K Inductive Proximity Sensors

₹ 2,340.90

Get Best Price on WhatsApp

Product Description

Parameter Value
Housing Metric
Housing Type Short-body
Thread Size M8 x 1
Diameter Ø 8 mm
Sensing Range (Sn) 2 mm
Safe Sensing Range (Sa) 1.62 mm
Installation Type Flush
Switching Frequency 4,000 Hz
Connection Type Cable, 3-wire, 2 m
Housing Length 32 mm
Thread Length 28 mm
Tightening Torque, max. Typ. 7 Nm (4)
  Typ. 14 Nm (5)
Protection Class III
UL File No. E181493



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1072697

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet
  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Metric

Housing - Short-body

Thread size - M8 x 1

Diameter - Ø 8 mm

Sensing range (Sn) - 2 mm

Safe sensing range (Sa) - 1.62 mm

Installation type - Flush

Switching frequency - 4,000 Hz

Connection type - Cable, 3-wire, 2 m

Switching output - PNP

Supply voltage - 10 V DC ... 30 V DC

Ripple - ≤ 10 %

Voltage drop - ≤ 2 V 1)

Hysteresis - 3 % ... 20 %

Reproducibility - ≤ 2 % 2) / 3)

Temperature drift (of Sr) - ± 10 %

EMC - According to EN 60947-5-2

Continuous current (Ia) - ≤ 200 mA

No load current - ≤ 10 mA

Cable material - PUR

MTTFD - 1,971 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Information according to Art. 3 of Data Act (Regulation EU 2023/2854) - ✔

ECLASS 5.1.4 - 27270101

ECLASS 6.0 - 27270101

ECLASS 7.0 - 27270101

ECLASS 8.0 - 27270101

ECLASS 9.0 - 27270101

ECLASS 10.0 - 27270101

ECLASS 11.0 - 27270101

ECLASS 12.0 - 27274001

ECLASS 13.0 - 27274001
