1074415 | SICK SENSORS | IMB30-15BPPVU2S Inductive Proximity Sensors

₹ 5,563.80

Get Best Price on WhatsApp

Product Description

Housing Metric
Housing Standard design
Thread size M30 x 1.5
Diameter Ø 30 mm
Sensing range Sn 15 mm
Safe sensing range Sa 12.15 mm
Installation type Flush
Switching frequency 500 Hz
Connection type Cable, 4-wire, 2 m
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 60 mm
Thread length 55 mm



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1074415

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet
  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Standard design

Thread size - M30 × 1.5

Diameter - Ø 30 mm

Sensing range Sn - 15 mm

Safe sensing range Sa - 12.15 mm

Installation type - Flush

Switching frequency - 500 Hz

Connection type - Cable, 4-wire, 2 m

Supply voltage - 10 V DC to 30 V DC

Ripple - ≤ 10 %

Voltage drop - ≤ 2 V

Hysteresis - 3 % to 20 %

Reproducibility - ≤ 2 %

Temperature drift (of Sr) - ± 10 %

EMC - According to EN 60947-5-2

Continuous current Ia - ≤ 200 mA

No load current - ≤ 10 mA

Cable material - PUR

Conductor size - 0.34 mm²

MTTFD - 2,016 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Information according to Art. 3 of Data Act (Regulation EU 2023/2854) - ✔

ECLASS 5.1.4 - 27270101

ECLASS 6.0 - 27270101

ECLASS 7.0 - 27270101

ECLASS 8.0 - 27270101

ECLASS 9.0 - 27270101

ECLASS 10.0 - 27270101

ECLASS 11.0 - 27270101
