1079360 | SICK SENSORS | MPS-050CLTP0 Cylinder Sensors

₹ 24,798.60
Get Best Price on WhatsApp

Product Description
Measuring range 50 mm 1)
Housing length 65 mm
Switching output Push-pull: PNP/NPN
Output function Analog, IO-Link
Electrical wiring DC 4-wire
Analog output (voltage) 0 V ... 10 V
Analog output (current) 4 mA ... 20 mA
Supply voltage 12 V DC ... 30 V DC
Power consumption 42 mA, without load
Voltage drop ≤ 2 V
Continuous current Ia ≤ 100 mA 1)
Max. load resistance ≤ 500 Ω Power Output, at 24 V
Min. load resistance ≥ 2 kΩ 2)
Protection class III
Time delay before availability 0.15 s
Required magnetic field sensitivity, typ. 3 mT ... 12 mT
Resolution, typ. ≥ 50 µm
Linearity error, typ. 0.3 mm 3)
Repeat accuracy, typ. 0.1 mm 4)



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1079360

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Cylinder type - C-slot

Measuring range - 50 mm¹

Housing length - 65 mm

Switching output - Push-pull: PNP/NPN

Output function - Analog, IO-Link

Electrical wiring - DC 4-wire

Analog output (voltage) - 0 V ... 10 V

Analog output (current) - 4 mA ... 20 mA

Enclosure rating - IP67²

Supply voltage - 12 V DC ... 30 V DC

Power consumption - 42 mA, without load

Voltage drop - ≤ 2 V

Continuous current Ia - ≤ 100 mA¹

Max. load resistance - ≤ 500 Ω (Power Output, at 24 V)

Min. load resistance - ≥ 2 kΩ²

Protection class - III

Time delay before availability - 0.15 s

Required magnetic field sensitivity, typ. - 3 mT ... 12 mT

MTTFD - 176 years

DCavg - 0%

TM (mission time) - 20 years

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Information according to Art. 3 of Data Act (Regulation EU 2023/2854) - ✔

ECLASS 5.1.4 - 27270806

ECLASS 6.0 - 27270806

ECLASS 7.0 - 27270806

ECLASS 8.0 - 27270806

ECLASS 9.0 - 27270806

ECLASS 10.0 - 27270806

ECLASS 11.0 - 27270806

ECLASS 12.0 - 27274301
