1089658 | SICK SENSORS | IMB08-02BPSVU5S Inductive Proximity Sensors

₹ 6,307.20

Get Best Price on WhatsApp

Product Description

Housing Metric
Housing Standard design
Thread size M8 x 1
Diameter Ø 8 mm
Sensing range Sn 2 mm
Safe sensing range Sa 1.62 mm
Installation type Flush
Switching frequency 4,000 Hz
Connection type Cable, 3-wire, 5 m
Housing length 45 mm
Thread length 41 mm
Tightening torque, max.

Typ. 7 Nm 4)

Typ. 14 Nm 5)

Protection class III



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1089658

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet
  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Metric

Housing - Standard design

Thread size - M8 x 1

Diameter - Ø 8 mm

Sensing range Sn - 2 mm

Safe sensing range Sa - 1.62 mm

Installation type - Flush

Switching frequency - 4,000 Hz

Connection type - Cable, 3-wire, 5 m

Switching output - PNP

Supply voltage - 10 V DC ... 30 V DC

Ripple - ≤ 10 %

Voltage drop - ≤ 2 V

Hysteresis - 3 % ... 20 %

Reproducibility - ≤ 2 %

Temperature drift (of Sr) - ± 10 %

EMC - According to EN 60947-5-2

Continuous current Ia - ≤ 200 mA

No load current - ≤ 10 mA

Cable material - PUR

MTTFD - 1,971 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Information according to Art. 3 of Data Act (Regulation EU 2023/2854) - ✔

ECLASS 5.1.4 - 27270101

ECLASS 6.0 - 27270101

ECLASS 7.0 - 27270101

ECLASS 8.0 - 27270101

ECLASS 9.0 - 27270101

ECLASS 10.0 - 27270101

ECLASS 11.0 - 27270101
