1109743 | SICK SENSORS | KTM-LP227A2P Contrast Sensors

₹ 28,685.70
Get Best Price on WhatsApp

Product Description
Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm
Sensing distance ≤ 50 mm
Sensing distance tolerance ± 30 mm
Housing design Small
Light source Laser, red 1)
Laser class I
Wave length 680 nm
Light emission Long side of housing
Light spot size Ø 1.7 mm (50 mm)
Light spot direction Round
Receiving filters None
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 5 Vpp 1)
Current consumption < 35 mA 2)
Switching frequency 4 kHz 3)
Response time 125 µs 4)
Jitter 57 µs
Accuracy 0.08 mm
Switching output PNP



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1109743

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing Design - Small

Dimensions (W × H × D) - 12 mm × 31.5 mm × 21 mm

Light Source - Laser, visible red light

Light Emission - Long side of housing

Light Spot Size - Ø 1.7 mm (50 mm)

Light Spot Direction - Round

Receiving Filters - None

Wavelength - 680 nm

Laser Class - I

Supply Voltage - 10 V DC ... 30 V DC

Ripple - ≤ 5 Vpp

Current Consumption - < 35 mA

Switching Frequency - 4 kHz

Response Time - 125 µs

Jitter - 57 µs

Accuracy - 0.08 mm

Switching Output - PNP

Switching Output (Voltage) - PNP: HIGH = UV ≤ 2 V / LOW approx. 0 V

Switching Mode - Light/Dark Switching

Housing Material - ABS

Optics Material - PMMA

Weight - Approx. 24 g

Not applicable for this product

EU Declaration of Conformity - ✔

UK Declaration of Conformity - ✔

ACMA Declaration of Conformity - ✔

Moroccan Declaration of Conformity - ✔

China RoHS - ✔

cULus Certificate - ✔

IO-Link Certificate - ✔

Information according to Art. 3 of Data Act (EU 2023/2854) - ✔

ECLASS 5.1.4 - 27270906

ECLASS 6.0 - 27270906

ECLASS 7.0 - 27270906

ECLASS 8.0 - 27270906

ECLASS 9.0 - 27270906

ECLASS 10.0 - 27270906

ECLASS 11.0 - 27270906

ECLASS 12.0 - 27270906

ECLASS 13.0 - 27270906
