1115223 | SICK SENSORS | CSS-WBF114118RZZZZ Color Sensor : CSS/CSX High Speed

₹ 47,492.10
Get Best Price on WhatsApp

Product Description
Dimensions (W x H x D) 26 mm x 62 mm x 47.5 mm
Sensing distance 13 mm
Sensing distance tolerance ± 5 mm
Housing design S housing
Light source LED, RGB 1)
LED risk group marking 1
Wave length 460 nm, 530 nm, 625 nm
Light emission Long side of housing
Light spot size 2 mm x 4 mm
Light spot direction Vertical 2)
Supply voltage 10.8 V DC ... 28.8 V DC 1)
Ripple ≤ 5 Vpp 2)
Current consumption < 120 mA 3)
Switching frequency 13.8 kHz
Response time 36 µs
Jitter 18 µs
Switching output Push-pull: PNP/NPN
Switching output (voltage) Push-pull: PNP/NPN HIGH = UV - 3 V/LOW ≤ 3 V
Output current Imax. 100 mA 4)
Input, teach-in (ET) Teach: U = 10 V ... < VS
Input, blanking input (AT) Blanked: U = 10 V ... < Uv
Retention time (ET) 3 s, non-volatile memory
Connection type Male connector M12, 8-pin



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1115223

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Parameter presettings - None

Housing design - Small

Dimensions (W × H × D) - 26 mm × 62 mm × 47.5 mm

Light source - LED, RGB ¹

Light emission - Long side of housing

Light spot size - 2 mm × 4 mm

Light spot direction - Vertical ²

Wave length - 460 nm, 530 nm, 625 nm

LED risk group marking - 1

Supply voltage - 10.8 V DC … 28.8 V DC ¹

Ripple - ≤ 5 Vpp ²

Current consumption - < 120 mA ³

Switching frequency - 13.8 kHz

Response time - 36 µs

Jitter - 18 µs

Switching output - Push-pull: PNP/NPN

Switching output (voltage) - PNP/NPN: HIGH = UV − 3 V / LOW ≤ 3 V

Output current Imax. - 100 mA ⁴

Housing material - VISTAL®

Optics material - PMMA

Weight - 68 g

Not applicable for this product

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Not applicable for this product
