130805 | FESTO | Push-in T-connector QST-10-50

₹ 548.81

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

130805

Fabricant d'équipement d'origine

FESTO

Description

Property Value
Size Standard
Nominal size 8.1 mm
Mounting position optional
Design T-shape
Size of pack 50
Design Push-pull principle
Operating pressure complete temperature range -0.095 MPa ... 0.6 MPa
Operating pressure complete temperature range -0.95 bar ... 6 bar
Operating pressure complete temperature range -13.775 psi ... 87 psi
Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa
Temperature-dependent operating pressure -0.95 bar ... 14 bar
Temperature-dependent operating pressure -13.775 psi ... 203 psi
Note on operating pressure Water: max. 0.6 MPa at max. 50°C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Water (liquid, ice-free)
Note on operating and pilot medium Lubricated operation possible
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Ambient temperature -10 °C ... 80 °C
Product weight 25 g
Number of outputs 2
Number of supply lines 1
Pneumatic connection, port 1 For tubing outer diameter of 10 mm
Pneumatic connection, port 2 For tubing outside diameter of 10 mm
Colour of release ring Blue
Note on materials RoHS-compliant
Material housing PBT
Material release ring POM
Material tubing seal NBR
Material tubing clamp component High-alloy stainless steel
