SPARECRUX is NOT an authorized distributor for FESTO

150857 | FESTO | Proximity Sensor

₹ 8,325.73

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

150857

Fabricant d'équipement d'origine

FESTO

Description
Parameter Specification
Design For T-slot
Conforms to Standard EN 60947-5-2
Symbol 00991148
Approval RCM trademark, CE mark (see declaration of conformity), UKCA marking (see declaration of conformity)
Compliance EU EMC Directive, EU RoHS Directive, UK EMC instructions, UK RoHS instructions
Note on Materials RoHS-compliant
Instructions on Use Support / actuator-sensor overview "The right sensor for the actuator"
Measured Variable Position
Measuring Principle Magnetic reed
Ambient Temperature -40 °C … 70 °C
Repetition Accuracy 0.2 mm
Switching Output Contacting, bipolar
Switching Element Function N/O contact
Reproducibility of Switching Value ±0.1 mm
Switch-on Time 0.5 ms
Switch-off Time 0.03 ms
Max. Switching Frequency 800 Hz
Max. Output Current 500 mA
Max. Switching Capacity AC 10 VA
Max. Switching Capacity DC 10 W
Inductive Protective Circuit Adapted to MZ, MY, ME coils
Short Circuit Current Rating No
Overload Protection Not available
Operational Voltage Range AC 12 V … 30 V
