SPARECRUX is NOT an authorized distributor for FESTO

151165 | FESTO | One-way Flow Control Valve GRLA-1/8-B

₹ 454.59

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

151165

Fabricant d'équipement d'origine

FESTO

Description
Property Specification
Valve function Exhaust air one-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Slotted head screw
Type of mounting Screw-in
Standard nominal flow rate in flow control direction 340 l/min
Standard nominal flow rate in blocked direction 260 l/min ... 420 l/min
Ambient temperature -10 °C ... 60 °C
Maritime classification See certificate
Explosion protection Zone 1 (ATEX), Zone 2 (ATEX),
Zone 21 (ATEX), Zone 22 (ATEX)
The information in the certificate must be observed!
Mounting position Optional
Symbol 00991452
Operating pressure complete temperature range 0.3 bar ... 10 bar
Standard flow rate in flow control direction 0.6->0 MPa 615 l/min
Standard flow rate in non-return direction 0.6->0 MPa 470 l/min ... 760 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Media temperature -10 °C ... 60 °C
Max. tightening torque 6 Nm
Product weight 28 g
Material screwed plug Wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR
Material adjusting screw Brass
Material swivel fitting Die-cast zinc
FESTO

151165 | FESTO | One-way Flow Control Valve GRLA-1/8-B

₹ 454.59
Property Specification
Valve function Exhaust air one-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Slotted head screw
Type of mounting Screw-in
Standard nominal flow rate in flow control direction 340 l/min
Standard nominal flow rate in blocked direction 260 l/min ... 420 l/min
Ambient temperature -10 °C ... 60 °C
Maritime classification See certificate
Explosion protection Zone 1 (ATEX), Zone 2 (ATEX),
Zone 21 (ATEX), Zone 22 (ATEX)
The information in the certificate must be observed!
Mounting position Optional
Symbol 00991452
Operating pressure complete temperature range 0.3 bar ... 10 bar
Standard flow rate in flow control direction 0.6->0 MPa 615 l/min
Standard flow rate in non-return direction 0.6->0 MPa 470 l/min ... 760 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Media temperature -10 °C ... 60 °C
Max. tightening torque 6 Nm
Product weight 28 g
Material screwed plug Wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR
Material adjusting screw Brass
Material swivel fitting Die-cast zinc
