151852 | FESTO | Solenoid Valve JMFH-5/2-D-2-C

₹ 8,703.93

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

151852

Fabricant d'équipement d'origine

FESTO

Description

Specification Details
Valve function 5/2 bistable
Type of actuation Electric
Construction width 54 mm
Standard nominal flow rate 2300 l/min (standardised to DIN 1343)
Pneumatic working port Sub-base size 2 to ISO 5599-1, G3/8
Operating voltage Via solenoid coil (ordered separately)
Operating pressure 0.2 MPa to 1 MPa (2 bar to 10 bar)
Design Piston gate valve
Approval c UL us - Recognized (OL)
Maritime classification See certificate
Certificate issuing authority DNV-TAA000032X, UL MH19482
Degree of protection IP65
Nominal size 11.5 mm
Grid dimension 56 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
Conforms to standard ISO 5599-1
Manual override Detenting via accessory / Non-detenting
ISO code 255
Type of piloting Pilot actuated
Pilot air supply Internal
Flow direction Non-reversible
Symbol 00991005
Lap Overlap
Switching time reversal 18 ms
Max. positive test pulse with 0 signal 2200 µs
Max. negative test pulse with 1 signal 3700 µs
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
