SPARECRUX is NOT an authorized distributor for FESTO

152589 | FESTO | Plastic Tubing PUN-12X2-SI

₹ 8,630.75

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

152589

Fabricant d'équipement d'origine

FESTO

Description

Parameter Value
Outside diameter 12 mm
Inside diameter 8 mm
Flow-relevant bending radius 62 mm
Min. bending radius 33 mm
Instructions on use TPE-U Ester based. The plastic tubing can only be installed in contact with cables if the sheathing is free of phosphoric acid esters. Otherwise, the plastic tubing may get damaged.
Tubing characteristics Suitable for energy chains
Operating pressure (complete temperature range) -0.095 MPa ... 0.7 MPa / -0.95 bar ... 7 bar / -13.775 psi ... 101.5 psi
Temperature-dependent operating pressure -0.095 MPa ... 1 MPa / -0.95 bar ... 10 bar / -13.775 psi ... 145 psi
Approval German Technical Control Board (TÜV)
Certificate issuing authority B 013277 0506 00
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Fire test material UL94 HB
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -35 °C ... 60 °C
Product weight according to length 0.0767 kg/m
Pneumatic connection For push-in connector outside diameter of 12 mm
Colour Silver
Shore hardness D 52 +/-3
Note on materials RoHS-compliant
