SPARECRUX is NOT an authorized distributor for FESTO

153159 | FESTO | Push-in Bulkhead Connector QSS-8

₹ 262.95

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

153159

Fabricant d'équipement d'origine

FESTO

Description
Feature Specification
Size Standard
Nominal Size 7 mm
Mounting Position Optional
Design Bulkhead, Push-pull principle
Pack Size 10
Operating Pressure (Complete Temp Range) -0.095 MPa ... 0.6 MPa -0.95 bar ... 6 bar -13.775 psi ... 87 psi
Temperature-dependent Operating Pressure -0.095 MPa ... 1.4 MPa -0.95 bar ... 14 bar -13.775 psi ... 203 psi
Note on Operating Pressure Water: max. 0.6 MPa at max. 50°C
Operating Medium Compressed air (ISO 8573-1:2010 [7:-:-]), Water (liquid, ice-free)
Lubrication Note Lubricated operation possible
Corrosion Resistance Class (CRC) 1 – Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class Class 4 (ISO 14644-1)
Ambient Temperature Range -10 °C to 80 °C
Product Weight 19 g
Mounting Type External hexagon, A/F 19 mm
Pneumatic Connection – Port 1 For tubing outer diameter of 8 mm
Pneumatic Connection – Port 2 For tubing outer diameter of 8 mm
Colour of Release Ring Blue
RoHS Compliance Yes
Material – Housing Anodised aluminium
Material – Release Ring POM
Material – Nut Nickel-plated brass
Material – Tubing Seal NBR
Material – Tubing Clamp Component High-alloy stainless steel
