SPARECRUX is NOT an authorized distributor for FESTO

153356 | FESTO | Push-in T-fitting QSMT-M5-6

₹ 228.72

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

153356

Fabricant d'équipement d'origine

FESTO

Description

Parameter Specification
Size Mini
Nominal size 2.1 mm
Type of seal on screwed plug Sealing ring
Mounting position Optional
Design T-shape
Size of pack 10
Design (principle) Push-pull principle
Operating pressure (complete temperature range) -0.095 MPa ... 0.6 MPa
-0.95 bar ... 6 bar
-13.775 psi ... 87 psi
Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa
-0.95 bar ... 14 bar
-13.775 psi ... 203 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible
Corrosion resistance class (CRC) 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10 °C ... 80 °C
Nominal torque 1.2 Nm
Tolerance for nominal tightening torque ± 20%
Product weight 5.6 g
Number of outputs 2
Number of supply lines 1
Type of mounting External hexagon, A/F 8 mm
Pneumatic connection, port 1 Male thread M5
Pneumatic connection, port 2 For tubing outside diameter of 6 mm
Colour of release ring Blue
Material screwed plug Nickel-plated brass
Note on materials RoHS-compliant
Material housing PBT
Material release ring POM
Material tubing seal NBR
Material tubing clamp component High-alloy stainless steel
