SPARECRUX is NOT an authorized distributor for FESTO

153425 | FESTO | Push-in Fitting, Self-sealing QSK-1/4-10

₹ 404.69

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

153425

Fabricant d'équipement d'origine

FESTO

Description
Category Specification
Size Standard
Nominal Size 4.8 mm
Approved Tubing Types PAN-, PAN-MF-, PAN-R-, PAN-V0-, PEN-, PFAN-, PLN-, PTFEN-, PUN-, PUN-CM-,PUN-DUO-, PUN-H-, PUN-H-DUO-, PUN-S-, PUN-S-DUO-, PUN-V0-
Tubing Insertion Depth 21 mm
Seal on Screwed Plug Coating
Mounting Position Optional
Design Straight designPush-pull principle
Pack Size 1
Operating Pressure (full temp. range) -0.095 MPa to 0.6 MPa-0.95 bar to 6 bar-13.775 psi to 87 psi
Temp-dependent Operating Pressure -0.095 MPa to 1.4 MPa-0.95 bar to 14 bar-13.775 psi to 203 psi
Operating Medium Compressed air to ISO 8573-1:2010 [7:-:-]
Lubrication Note Lubricated operation possible
Corrosion Resistance Class (CRC) 1 – Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Ambient Temperature Range -10 °C to +80 °C
Nominal Torque 9 Nm
Torque Tolerance ± 20%
Product Weight 32 g
Mounting Type External hexagon, size 17 mm
Pneumatic Connection - Port 1 Male thread R1/4
Pneumatic Connection - Port 2 For tubing outside diameter of 10 mm
Release Ring Color Blue
RoHS Compliance Yes
Material – Housing Brass, nickel-plated
Material – Release Ring POM
Material – Tubing Seal NBR
