156520 | FESTO | Compact Cylinder ADVU-20-40-P-A

₹ 4,136.32

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

156520

Fabricant d'équipement d'origine

FESTO

Description

Feature Specification
Stroke 40 mm
Piston diameter 20 mm
Piston rod thread M5
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Female thread
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.1 MPa ... 1 MPa (1 bar ... 10 bar, 14.5 psi ... 145 psi)
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubrication Lubricated operation possible
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.14 J
Theoretical force at 6 bar (return stroke) 141 N
Theoretical force at 6 bar (advance stroke) 188 N
Moving mass for 0 mm stroke 20 g
Additional moving mass per 10 mm stroke 6 g
Basic weight for 0 mm stroke 149 g
Additional weight per 10 mm stroke 23 g
Type of mounting With through-hole / With accessories
Pneumatic connection M5
Material collar screws Galvanised steel
Material cover Wrought aluminium alloy
Material dynamic seals NBR, TPE-U(PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel Wrought aluminium alloy
