SPARECRUX is NOT an authorized distributor for FESTO

156872 | FESTO | Compact cylinder ADVUL-25-40-P-A

₹ 23,224.65

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

156872

Fabricant d'équipement d'origine

FESTO

Description
Parameter Details
Stroke 40 mm
Piston diameter 25 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991737
Variants Piston rod at one end
Protection against torque/guide Guide rod with yoke
Operating pressure 0.1 MPa ... 1 MPa (1 bar ... 10 bar)
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.1 J
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 247 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 295 N
Moving mass for 0 mm stroke 61 g
Additional moving mass per 10 mm stroke 11 g
Basic weight for 0 mm stroke 215 g
Additional weight per 10 mm stroke 28 g
Type of mounting Either with through-hole or with accessories
Pneumatic connection M5
Material collar screws Galvanised steel
Material cover Wrought aluminium alloy
Material dynamic seals NBR, TPE-U(PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel Wrought aluminium alloy
