SPARECRUX is NOT an authorized distributor for FESTO

3629 | FESTO | Roller Lever Valve R-3-M5

₹ 961.45

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

3629

Fabricant d'équipement d'origine

FESTO

Description

Category Specification
Valve function 3/2-way, closed, monostable
Type of actuation Mechanical
Standard nominal flow rate 80 l/min (standardised to DIN 1343)
Pneumatic working port M5
Operating pressure -0.95 bar to 8 bar
Design Poppet seat
Nominal size 2 mm
Type of piloting Direct
Symbol 00991097
Explosion protection Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX)
Operating medium Compressed air to ISO 8573-1:2010 [-:-:-]
Note on operating and pilot medium Lubricated operation possible (then always required)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10 °C to +60 °C
Actuating force 16.5 N
Product weight 40 g
Type of mounting With through-hole
Pneumatic connection, port 1 M5
Pneumatic connection, port 2 M5
Material seals NBR
Material housing Die-cast zinc
