SPARECRUX is NOT an authorized distributor for FESTO

36487 | FESTO | Bellows Cylinder EB-165-65

₹ 13,069.94

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

36487

Fabricant d'équipement d'origine

FESTO

Description

Parameter Value
Size 165
Required installation diameter 180 mm
Stroke 65 mm
Max. extended height 115 mm
Max. angle of inclination 20 deg
Max. offset 10 mm
Min. installation height 51 mm
Mode of operation Single-acting
Symbol 00991205
Operating pressure 0 bar ... 8 bar
Operating medium Compressed air to ISO 8573-1:2010 [-:-:4]
Note on operating and pilot medium Lubricated operation not possible
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -40 °C ... 70 °C
Reset force 200 N
Product weight 1200 g
Type of mounting Via female thread
Pneumatic connection G1/4
Note on materials RoHS-compliant
Material bellows NR/BR
Material housing Steel, Galvanised
