SPARECRUX is NOT an authorized distributor for FESTO

4233 | FESTO | Pneumatic Valve VL/O-3-PK-3

₹ 6,392.51

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

4233

Fabricant d'équipement d'origine

FESTO

Description
Specification Details
Valve function 3/2 open, monostable
Standard nominal flow rate (DIN 1343) 100 l/min
Pneumatic working port PK-3
Operating pressure 0 bar ... 8 bar
Design Poppet seat
Nominal size 2.5 mm
Symbol 00991030
Switching time off 50 ms
Switching time on 12 ms
Explosion protection The information in the certificate must be observed!
Zone 1 (ATEX)
Zone 2 (ATEX)
Zone 21 (ATEX)
Zone 22 (ATEX)
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Pilot medium Compressed air to ISO 8573-1:2010 [7:-:-]
Ambient temperature -10 °C ... 60 °C
Product weight 110 g
Type of mounting Either:
On sub-base
On mounting frame
With through-hole
Pneumatic connection, port 1 PK-3
Pneumatic connection, port 4 PK-3
Pneumatic connection, port 5 PK-3
Material sub-base Brass, PPS reinforced
Material seals NBR
Material housing Die-cast zinc
FESTO

4233 | FESTO | Pneumatic Valve VL/O-3-PK-3

₹ 6,392.51
Specification Details
Valve function 3/2 open, monostable
Standard nominal flow rate (DIN 1343) 100 l/min
Pneumatic working port PK-3
Operating pressure 0 bar ... 8 bar
Design Poppet seat
Nominal size 2.5 mm
Symbol 00991030
Switching time off 50 ms
Switching time on 12 ms
Explosion protection The information in the certificate must be observed!
Zone 1 (ATEX)
Zone 2 (ATEX)
Zone 21 (ATEX)
Zone 22 (ATEX)
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Pilot medium Compressed air to ISO 8573-1:2010 [7:-:-]
Ambient temperature -10 °C ... 60 °C
Product weight 110 g
Type of mounting Either:
On sub-base
On mounting frame
With through-hole
Pneumatic connection, port 1 PK-3
Pneumatic connection, port 4 PK-3
Pneumatic connection, port 5 PK-3
Material sub-base Brass, PPS reinforced
Material seals NBR
Material housing Die-cast zinc
