SPARECRUX is NOT an authorized distributor for FESTO

536220 | FESTO | Compact Cylinder ADN-16-10-A-P-A

₹ 1,722.16

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

536220

Fabricant d'équipement d'origine

FESTO

Description

Property Value
Stroke 10 mm
Piston diameter 16 mm
Piston rod thread M6
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Male thread
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Moving mass 22 g
Product weight 89 g
Pneumatic connection M5
Note on materials RoHS-compliant
Material collar screws Steel
Material cover Anodised wrought aluminium alloy
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Smooth-anodised wrought aluminium alloy
FESTO

536220 | FESTO | Compact Cylinder ADN-16-10-A-P-A

₹ 1,722.16
Property Value
Stroke 10 mm
Piston diameter 16 mm
Piston rod thread M6
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Male thread
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Moving mass 22 g
Product weight 89 g
Pneumatic connection M5
Note on materials RoHS-compliant
Material collar screws Steel
Material cover Anodised wrought aluminium alloy
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Smooth-anodised wrought aluminium alloy
