SPARECRUX is NOT an authorized distributor for FESTO

536261 | FESTO | Compact Cylinder ADN-25-15-I-P-A

₹ 2,057.54

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

536261

Fabricant d'équipement d'origine

FESTO

Description
Parameter Value
Stroke 15 mm
Piston diameter 25 mm
Piston rod thread M6
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Conforms to standard ISO 21287
Piston-rod end Female thread
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.06 MPa ... 1 MPa0.6 bar ... 10 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 5 according to ISO 14644-1
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.3 J
Theoretical force at 0.6 MPa (return stroke) 247 N
Theoretical force at 0.6 MPa (advance stroke) 295 N
